Totally-enclosed, cylindrical bags are ideal for shallow water salvage, reducing the draft of a vessel or raising an object closer to the surface. They are invaluable in cable and pipeline operations and where long tows are planned.
Fabric:
-
Urethane-coated nylon - high-strength and heavy-duty
-
Superior abrasion resistance
-
Resistant to most petro-chemicals
-
UV-resistant
-
Low maintenance requirements and easy to clean
-
RF welded seams
Fittings:
-
Replaceable, heavy-duty nylon webbing lift harness is built into the body of the lift bag, with a safe working ratio of 6:1
-
The harness maintains the lift bag in a horizontal position while insuring maximum stability
-
Equipped with shackles, valves and all necessary hardware for immediate use
-
3/4" NPT inflation port with 3/4" stainless steel ball valves for inflation and deflating
-
Stainless steel quick disconnect for inflation
-
Pressure relief valves set to release at 2.5psi above ambient pressure
CAUTION: Salvage Pontoons have multiple attachment points. All attachment points must be connected with the shackles provided, and the load evenly distributed. Large pontoons may require a separate lifting beam to evenly distribute the load.
Each SUBSALVE USA lift bag is tested prior to shipping.
Custom sizes available.
All Subsalve USA products are compliant with IMCA D-016-AIRBAGS, ABS, U.S. Department of Defense Standards.
We would send you a freight quote after you place your order. Freight fees (for USA) usually vary between $300-$700 and are based on weight, dimensions, destination etc.
|
|
|
 |
|
 |
|
